High Production Microfishe Scanner

Product Description

Highlights

Easy-access tabs allow for quick job set-up without the need for elaborate and confusing wizards Advanced menus for detailed image enhancement features Dual-view capability to view bi-tonal and grayscale images simultaneously without impacting speed Image quality control and rescan window that allows for real-time image enhancement Flexible and simple to use file naming capability EASY TO USE SOFTWARE CREATES ADDED VALUE COM. Jackets. Step and Repeat. Using the latest in Mekel’s CCD, lens and patented “smoothlight” fiber optic technology, these fiche scanners demonstrate an ability to seamlessly convert any format of microfiche to various electronic image formats. Providing the highest optical dpi in the industry, the MACH series microfiche scanners deliver clear and consistent image quality while automatically regulating density variations common to many microfiche. Image processing features include: In addition to superior image quality, the MACH VII fiche scanner is designed to operate at speeds of up to 200 images per minute. The MACH VI fiche scanner, a mid-range unit, achieves up to 100 images per minute. Both pieces can create both bi-tonal and grayscale images simultaneously without impacting speed. HIGH PERFORMANCE MICROFICHE SCANNERS VERSATILITY AND IMAGE QUALITY HIGH SPEED LEADING THE INDUSTRY The Mekel MACH series microfiche scanners are the most advanced fiche scanning systems on the market  today. Designed to handle various microfiche and jacket formats, the MACH VI and MACH VII create superior image quality at high speeds from even the most difficult Film. Designed for service bureaus, institutions, agencies and other large volume end-users, the MACH series microfiche scanners have a reputation as the most automated, reliable, hardest-working and  easiest-to-use equipment in the industry. , the MACH series microfiche scanner software, virtually eliminates the software learning curve. The simple-to-use sliders, preview screens and flexibility often reserved for more sophisticated applications ensure that even a first-time operator will be scanning within hours of installation and training. Automatic image enhancement

Features allow for nearly unattended scanning without sacrificing image quality. Automatic crop Automatic invert

Automatic deskew

Automatic rotation

Automatic mirror

Software focus

Camera/Optics 12-bit dynamic range with gamma correction grayscale output. Full depth of pixels processed Advanced adaptive Automatic Gain Control (AGC). Handles varying film density in real-time across the film 80 megapixel/second camera; 160 megapixel/second output Full 8,192 pixel CCD array for highest optical dpi in the industry Mekel “smoothlight” fiber optic bundle offers balanced lighting across the entire scan area with no hotspots or shadowing

Resolution Film Handling Speed (fully processed) Fiche Formats Frame Detection Title Bar/Full Fiche Imaging Viewing/Browsing File Formats Operating System Power Requirements Agency Approvals

Hands-free automatic loading/unloading or manual loading/unloading

Input hopper capacity up to 75 fiche

24x/200 dpi – up to 150 ppm

42x/200 dpi – up to 150 ppm

48x/200 dpi – up to 200 ppm

24x/200 dpi – up to 75 ppm

42x/200 dpi – up to 75 ppm

48x/200 dpi – up to 100 ppm

Supports all standard fiche types including standard or long jackets; COM; AB Dick; Ultra Fiche and Microx. Images can be 16mm or 35mm; combo 16mm/35mm; simplex or duplex; positive or negative; Diazo; Silver; Vesicular; duplicates; cine/comic mode  Single-pass intelligent prescan automatically detects all images regardless of size or location  Presence Prescan feature allows for faster throughput on COM by automatically detecting and scanning only those frames that contain data Image Processing Continuous automatic scanning Interactive selection of individual images or automatic capture of entire fiche row as an individual image Real-time automatic and manual control of rotation, cropping, deskew and automatic compression of  film background density variations Real-time image processing provides 5x the typical processing speed Task set-up by job or saved in set-up file Fully- and/or user-definable title bar can be saved along with images scanned from fiche (opaque or translucent) Full fiche prescan image can also be saved along with images scanned from fiche

Full or partial screen in real-time or by thumbnail, emulating fiche layout Real-time dual view of bi-tonal and grayscale images

All Standard TIFF, CCITT 4, G3, G4 (bi-tonal) and JPEG for grayscale (true 256 shades of gray)

Simultaneous output of grayscale and bi-tonal formats

Windows XP utilizing Mekel

50Hz or 60Hz/100v to 240v AC/800 watt single-phase, switchable for domestic and international use

FCC, UL and CE certification 100-600 true optical dpi MACH VII MACH VI Hardware Image Enhancement Real-time image sharpen and enhancement done in hardware; no reduction in throughput Dell high-end multi-processor, multi-core workstation ensure maximum uptime and performance. Please request current specs scanning software
