Microfilm Roll Scanner

Product Description

The Mekel MACH series roll film scanners are the most advanced systems on the market today. Designed to handle 16mm and 35mm film formats, these easy-to-use  machines and software create superior image quality at high speeds from even the most difficult film.  The first to introduce a microfilm scanner to the world in 1989, Mekel technology has remained at the forefront of the industry as evidenced by the efficiency and quality offered in the MACH III and MACH IV roll film scanners.  Designed for service bureaus, institutions, agencies and other large volume end-users, this MACH series uses the latest in camera, lens and light source technology and demonstrates the ability to seamlessly convert both 16mm and 35mm roll microfilm into various electronic image formats. Providing the highest optical dpi in the industry, the MACH series scanners deliver clear and consistent image quality automatically while regulating density variations common to all microfilm. In addition to superior image quality, the MACH III is designed to operate at speeds of up to 180 images/360 files per minute. The MACH IV can process up to 325 images/650 files per minute. Both film roll scanners can create both bi-tonal and grayscale images simultaneously with no impact on speed.

Various image-processing features include:

, the custom-designed MACH series roll film software, has unparalleled ease-of-use. Simple to use sliders, preview screens and the flexibility often reserved for more sophisticated applications ensure that even a first-time operator will be running full speed within hours of installation and training. Automatic image enhancement features allow for nearly unattended scanning without sacrificing image quality. TRADITIONAL ROLL FILM SCANNERS HIGH PERFORMANCE SCANNING SETTING THE INDUSTRY STANDARD FOR QUALITY FILLING THE NEED FOR SPEED HIT THE GROUND RUNNING Automatic crop Automatic mirror Automatic deskew Automatic rotation Automatic invert Software focus Camera/Optics ACH III  180 images/360 files per minute at 200 dpi MACH IV  325 images/650 files per minute at 200 dpi No adaptive speed control necessary 12-bit dynamic range with gamma correction grayscale output. Full depth of pixels processed Real-time image processing provides 5x the typical processing speed Direct path imaging: camera, film and light source are in-line to ensure optimum image quality 80 megapixel/second camera; 160 megapixel/second output Full 8,192 pixel CCD array for highest true optical dpi in the industry Automatic Gain Control (AGC) to optimize image quality while scanning Mekel “smoothlight” fiber optic bundle offers balanced lighting across the entire scan area with no hot spots or shadowing.

Accepts ANSI, M-types and open spools 16mm/35mm; simplex/duplex; positive/negative Silver, Diazo or Vesicular formats 1,000 foot roll standard Film Control Film cleaning rollers; custom technology cleans film as it scans Electronically-controlled film format selection for precise positioning of the CCD camera and lens High speed rewind Cleaning True fast scan with all processing; speed is never compromised Task set-up by job saved in set-up file Single, double or triple level blip code detection as well as single- or dual-level leading and trail edge detection Image Processing Frame Detection Windows XP or Vista utilizing Mekel scanning software 50Hz or 60Hz; 100v - 240v; 500w, single phase switch for domestic or international use FCC, UL and CE certification Dell high-end multi-processor, multi-core workstation ensures maximum uptime and performance. Please request current specs Operating System Power Requirements Agency Approvals

HIGHLIGHTS Easy-access tabs to allow for quick project set-up without the need for elaborate and confusing wizards Advanced menus for detailed image enhancement features Dual-view capability to view bi-tonal and grayscale images simultaneously without impacting speed Image quality control and rescan window that allows for real-time image enhancement Flexible and simple to use file naming capability NOTE TO CURRENT MACH III and IV OWNERS: Ask about our new software and the

hardware upgrades that can give your Mekel microfilm scanner the power of full roll strip scanning at

a fraction of the cost of a new machine. For more information, contact

Speed (fully processed)

Resolution

Film Types

100-600 true optical dpi

Hardware Image Enhancement Real-time image sharpen and enhancement done in hardware; no reduction in throughput

FOR EVEN MORE ROBUST SCANNING, ASK ABOUT THE NEW

All Standard TIFF, CCITT 4, G3, G4 (bi-tonal) and JPEG for grayscale (true 256 shades of gray)

Simultaneous output of grayscale and bi-tonal formats

File Formats
